Denon AVR-X8500H Service Manual

5. Network / Bluetooth / USB
Check the setting
YES
YES
YES
YES
Are the network settings of this unit correct?
Are peripheral devices such as the router and
hub connected to this unit correctly?
Are the router settings correct?
Set the IP address, etc. correctly.
When the static IP address is used, check that no
other devices have the same IP address and that
the subnet mask settings are correct.
Connect the peripheral devices correctly.
Check the instruction manual of the router and
congure the settings correctly.
Check that there are no connection restrictions
by MAC addresses, etc.
5.1. Cannot connect to the network
Is the LAN cable correctly inserted?
Insert the LAN cable correctly and then turn on
the power again.
Check the connection environment
Checking the unit
YES
YES
YES
Can the output voltage (5V) to
[Q8007 : FET-SW] be con-
rmed?
Can the voltage (5V) be conrmed between
[N6001 : 2, 3pin - 4, 5pin]?
Is NET5V_POWER [U6201 :
uCOM 48pin] "Hi" ?
The circuit of NET5V_POWE
between [U6201 and Q8007]
are faulty.
The circuit around [Q8007 :
FET-SW] is faulty.
The circuit between the AC inlet and [N6001] is
faulty.
Check the SMPS PCB.
YES
YES
NO
NO
NO
NO
NO
NO
NO
NO
NO
Can the output voltage (1.2V)
to [Q8009 : FET-SW] be con-
rmed?
Is NET3.3V_POWER [U6201 :
uCOM 135pin] "Hi" ?
The circuit of NET3.3V_
POWER between [U6201 and
Q8009] are faulty.
The circuit around [Q8009 :
FET-SW] is faulty.
Go to next page.
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
89

Denon AVR-X8500H Specifications

General

Channels	13.2
Power Output	150W per channel (8 ohms, 20Hz-20kHz, 0.05% THD)
Frequency Response	10Hz-100kHz (+1, -3dB)
HDMI Inputs	8 (1 front)
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
HEOS Multi-room	Yes
Wi-Fi	Yes
Bluetooth	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Impedance	4-16 ohms
HDR Compatibility	HDR10, Dolby Vision, HLG
Audio Return Channel (ARC)	Yes
Digital Audio Inputs	2 Optical, 2 Coaxial
Analog Audio Inputs	6
Phono Input	Yes
Speaker Connectors	Binding Posts
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Surround Sound Support	Dolby Atmos, DTS:X, Auro-3D
Tuner	AM/FM
Input Sensitivity/Impedance	200 mV / 47 kohms
HDCP Support	2.2
Other Connections	USB, Ethernet, RS-232C
Wireless Connectivity	Wi-Fi, Bluetooth
Signal-to-Noise Ratio	102 dB
DAC	AKM AK4490EQ (32-bit/192kHz)
Total Harmonic Distortion	0.05% (20Hz - 20kHz, 150W)
