Denon AVR-X8500H Service Manual

4. Protection Pass Mode 6. Network Initialization Mode
4.1. Actions
• This mode allows the power to be turned on without activating protections.
• This mode functions in the same way as normal power-on, except that protections are not activated.
• When using the protection pass mode, do not connect speakers to the speaker terminals.
4.2. Operations
While holding down buttons "
ZONE3 SOURCE
", "
STATUS
" and "
CURSOR
0
" simultaneously, press
the power button to turn on the power.
The device returns to the normal display message after the following is displayed.
L1
Protection Pass
This is displayed for 5 seconds before returning to the normal display.
5. Additional Source mode
5.1. Actions
• These functions add Additional Source settings for use with the Custom installer. AUX 3-7 is added as
a source when these settings are enabled.
• Assign input terminals to AUX 3-7 in "Setup Menu" → "Input" → "Input Assign" to increase the num-
ber of usable input sources.
• The default factory setting is "OFF".
5.2. Starting up
While holding down buttons "BACK" and "CURSOR
f
" simultaneously, press the power button to turn
on the power.
5.3. Operations
(1) The Additional Source mode is displayed in FLD after the POWER ON sequence.
(2) Select settings using the "CURSOR
0
/
1
" buttons.
ON OFF
L1
*Add Source Mode
L2
< OFF >
• ON is selected.
L2
< ON >
• OFF is selected.
L2
< OFF >
(3) Press the "ENTER" button on the main unit to apply.
6.1. Actions
The following items are initialized.
(1) Network setup
(2) Friendly Name
(3) Auto Update setting
(4) Allow Update setting
(5) Time Zone setting
(6) Queue list
(7) Internet Radio recently played station
(8) Quick Select playback station
(9) AirPlay Password
(10) Bluetooth Pairing History
(11) Crestron Connected Setup
6.2. Operations
When the power is on and the input source is HEOS Music, press and hold the "
CURSOR
1
" and "
DIM-
MER
" buttons for more than 3 seconds.
Initializing Display
L1
Network Reset...
Complete Display
L1
Completed
This is displayed for 5 seconds before returning to the normal display.
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
148

Denon AVR-X8500H Specifications

General

Channels	13.2
Power Output	150W per channel (8 ohms, 20Hz-20kHz, 0.05% THD)
Frequency Response	10Hz-100kHz (+1, -3dB)
HDMI Inputs	8 (1 front)
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
HEOS Multi-room	Yes
Wi-Fi	Yes
Bluetooth	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Impedance	4-16 ohms
HDR Compatibility	HDR10, Dolby Vision, HLG
Audio Return Channel (ARC)	Yes
Digital Audio Inputs	2 Optical, 2 Coaxial
Analog Audio Inputs	6
Phono Input	Yes
Speaker Connectors	Binding Posts
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Surround Sound Support	Dolby Atmos, DTS:X, Auro-3D
Tuner	AM/FM
Input Sensitivity/Impedance	200 mV / 47 kohms
HDCP Support	2.2
Other Connections	USB, Ethernet, RS-232C
Wireless Connectivity	Wi-Fi, Bluetooth
Signal-to-Noise Ratio	102 dB
DAC	AKM AK4490EQ (32-bit/192kHz)
Total Harmonic Distortion	0.05% (20Hz - 20kHz, 150W)
