Explanatory Photos for DISASSEMBLY
• For the shooting direction of each photos used in this manual, see the photo below.
• A, B, C and D in the photo below indicate the shooting directions of photos.
• The photographs with no shooting direction indicated were taken from the top of the unit.
• Photos of AVR-X8500H E3 are used in this manual.
The viewpoint of each photograph
(Shooting direction : X) [View from the top]
↑Shooting direction: A↑
↓Shooting direction: B↓
↓Shooting direction: D↓
↑Shooting direction: C↑
↑
Front side
↑
Proceeding : TOP COVER → FRONT PANEL ASSY
(1) Remove the screws.
(2) Cut the wire clamps, then remove the STYLE PINs and connectors.
1. FRONT PANEL ASSY
View from the bottom
x12
N9024
N3403
N8001
FFC
CUT
STYLE PIN
CUT
