DISASSEMBLY
Flowchart
• Remove each part following the ow below.
• Reassemble the removed parts in the reverse order.
• Read "SAFETY PRECAUTIONS" before reassembling the removed parts.
• If wire bundles are removed or moved during adjustment or part replacement, reshape the wires after completing the work. Failure to shape the wires correctly may cause problems such as noise.
• See "EXPLODED VIEW"
FRONT PANEL ASSY
DISASSEMBLY
1. FRONT PANEL ASSY
and "EXPLODED VIEW"
HP PCB
Ref. No. of EXPLODED VIEW : B 02-2
FRONT HDMI PCB
Ref. No. of EXPLODED VIEW : B 02-5
FRONT USB PCB
Ref. No. of EXPLODED VIEW : B 02-9
FLD PCB
Ref. No. of EXPLODED VIEW : B 04-1
P.SW PCB
Ref. No. of EXPLODED VIEW : B 04-2
SOURCE PCB
Ref. No. of EXPLODED VIEW : B 04-3
VOLUME PCB
Ref. No. of EXPLODED VIEW : B 04-4
TOP COVER
TRANS
DISASSEMBLY
4. TRANS
and "EXPLODED VIEW"
POWER TRANS
Ref. No. of EXPLODED VIEW : M 11
RADIATOR ASSY
DISASSEMBLY
2. RADIATOR ASSY
and "EXPLODED VIEW"
L-AMP CONNECT PCB
Ref. No. of EXPLODED VIEW : B 02-3
R-AMP CONNECT PCB
Ref. No. of EXPLODED VIEW : B 02-4
POSISTER1,2 PCB
Ref. No. of EXPLODED VIEW : B 04-6,7
AMP2 PCB
Ref. No. of EXPLODED VIEW : B 05-1
AMP1 PCB
Ref. No. of EXPLODED VIEW : B 05-2
BACK PANEL ASSY
DISASSEMBLY
3. BACK PANEL ASSY
and "EXPLODED VIEW"
DIGITAL PCB
Ref. No. of EXPLODED VIEW : B 01
DAC PCB
Ref. No. of EXPLODED VIEW : B 06-1
SIDE CONNECT PCB
Ref. No. of EXPLODED VIEW : B 06-2
AUDIO VIDEO PCB
Ref. No. of EXPLODED VIEW : B 02-1
CONNECT-1 PCB
Ref. No. of EXPLODED VIEW : B 02-6
CONNECT-2 PCB
Ref. No. of EXPLODED VIEW : B 02-7
232C and PHONO PCB
Ref. No. of EXPLODED VIEW : B 04-5
CONNECT-4 PCB
Ref. No. of EXPLODED VIEW : B 02-8
SPEAKER PCB
Ref. No. of EXPLODED VIEW : B 03-1
HEIGHT2 SP PCB
Ref. No. of EXPLODED VIEW : B 03-2
HEIGHT3_4 SP PCB
Ref. No. of EXPLODED VIEW : B 03-3
SMPS PCB
Ref. No. of EXPLODED VIEW : B 05-3
NETWORK MODULE ASSY
Ref. No. of EXPLODED VIEW : B 07
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
75
