Denon AVR-X8500H Service Manual

Paths to be conrmed Display Settings What to conrm
3
DIGITAL
(ZONE2)
g.A03a
g.A03b
g.A03c
A03:DIGITAL-Z2
Input Source : HEOS Music
Input Mode : Auto
Sound mode : STEREO
Amp assign : 11.1ch + ZONE2
Speaker for ZONE2 : S.Back
Floor Layout : 5ch
Height Sp : 6ch
Dolby Sp : None
Height Layout : Front Height/Top Middle/Rear Height
MAIN ZONE : On
ZONE2 : On
ZONE3 : Off
・ Digital(PCM) input ⇒ Speaker output (S.Back L/R (ZONE2 L/R))
・ Digital(PCM) input ⇒ Pre OUT output (ZONE2 L/R)
(
b
The input source can be switched to any source except HEOS Music.)
4
DIGITAL
(ZONE3)
g.A04a
g.A04b
A04:DIGITAL-Z3
Input Source : HEOS Music
Input Mode : Auto
Sound mode : STEREO
Amp assign : 11.1ch + ZONE3
Speaker for ZONE3 : Height2
Floor Layout : 5ch
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height/Rear Height
MAIN ZONE : On
ZONE2 : Off
ZONE3 : On
・ Digital(PCM) input ⇒ Amp Assign Speaker output (Height2 L/R)
・ Digital(PCM) input ⇒ Pre OUT output (ZONE3 L/R)
(
b
The input source can be switched to any source except HEOS Music.)
5 HDMI
g.A05a
g.A05b
g.A05c
A05:HDMI
Input Source : CBL/SAT
Input Mode : HDMI (xed)
Sound mode : STEREO
Amp assign : 13.1ch
Floor Layout : 5ch&SB
Height Sp : 6ch
Dolby Sp : None
Height Layout : Front Height/Top Middle/Rear Height
MAIN ZONE : On
ZONE2 : Off
ZONE3 : Off
・ HDMI input ⇒ Speaker output (Front L/R)
・ HDMI input ⇒ Pre OUT output (Front L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
6
Analog AD
(MAIN ZONE)
g.A06a
g.A06b
A06:AD
Input Source : CBL/SAT
Input Mode : Analog (xed)
Sound mode : MULTI CH STEREO
Amp assign : 13.1ch
Floor Layout : 5ch&SB
Height Sp : 6ch
Dolby Sp : None
Height Layout : Front Height/Top Middle/Rear Height
Speaker Select : Floor
Speaker Cong ALL Speaker = Small/SW = Yes(2ch)
MAIN ZONE : On
ZONE2 : Off
ZONE3 : Off
・ Analog input ⇒ Speaker output
(Front L/R, Center, Surround L/R, S.Back L/R, Height1 L/R, Height2 L/R, Height3 L/R)
・ Analog input ⇒ Pre OUT output, SW(20Hz)
(Front L/R, Center, Surround L/R, S.Back L/R, Height1 L/R, Height2 L/R, Height3 L/R,
SubWoofer1/2)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
7
Analog Amp Assign
(Amp Assign :
ZONE2)
g.A07
A07:ASSIGN-Z2
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : STEREO
Z2 Source : Source
Amp assign : 11.1ch + ZONE2
Speaker for ZONE2 : S.Back
Floor Layout : 5ch
Height Sp : 6ch
Dolby Sp : None
Height Layout : Front Height/Top Middle/Rear Height
MAIN ZONE : On
ZONE2 : On
ZONE3 : Off
・ Analog input ⇒ Speaker output (S.Back L/R (ZONE2 L/R))
・ Analog input ⇒ Pre OUT output (ZONE2 L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
153

Denon AVR-X8500H Specifications

General

Channels	13.2
Power Output	150W per channel (8 ohms, 20Hz-20kHz, 0.05% THD)
Frequency Response	10Hz-100kHz (+1, -3dB)
HDMI Inputs	8 (1 front)
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
HEOS Multi-room	Yes
Wi-Fi	Yes
Bluetooth	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Impedance	4-16 ohms
HDR Compatibility	HDR10, Dolby Vision, HLG
Audio Return Channel (ARC)	Yes
Digital Audio Inputs	2 Optical, 2 Coaxial
Analog Audio Inputs	6
Phono Input	Yes
Speaker Connectors	Binding Posts
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Surround Sound Support	Dolby Atmos, DTS:X, Auro-3D
Tuner	AM/FM
Input Sensitivity/Impedance	200 mV / 47 kohms
HDCP Support	2.2
Other Connections	USB, Ethernet, RS-232C
Wireless Connectivity	Wi-Fi, Bluetooth
Signal-to-Noise Ratio	102 dB
DAC	AKM AK4490EQ (32-bit/192kHz)
Total Harmonic Distortion	0.05% (20Hz - 20kHz, 150W)
