Denon AVR-X8500H Service Manual

Paths to be conrmed Display Settings What to conrm
13 7.1ch g.A13
A19:7.1CH IN
Input Source : CBL/SAT
Input Mode : 7.1ch In
Amp assign : 13.1ch
Floor Layout : 5ch&SB
Height Sp : None
Dolby Sp : None
Speaker Cong ALL Speaker = Small/SW = Yes(2ch)
・ 7.1ch IN input ⇒ Speaker output (Front L/R, Center, Surround L/R, S.Back L/R)
・ 7.1ch IN input ⇒ Pre output (Front L/R, Center, Surround L/R, S.Back L/R, Subwoofer1/2)
14
Amp Assign Cus-
tom (Case1)
g.A14a
g.A14b
A24:CUSTOM1
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : MULTI CH STEREO
Amp assign : Custom
Floor Layout : 5ch&SB
Height Sp : 6ch
Dolby Sp : None
Height Layout : Front Height/Top Middle/Rear Height
Speaker Select=Floor & Height
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
Setting
Front Terminal : Rear Height
Surround Terminal : Top Middle
S.Back Terminal : Front Height
Height1 Terminal : S.Back
Height2 Terminal : Front
Height3 Terminal : Surround
・ Analog 入力 ⇒ Speaker 出力
(Front L/R (Rear Height), Surround L/R (Top Middle), S.Back L/R (Front Height), Height1 L/R
(S.Back), Height2 L/R (Front), Height3 L/R (Surround))
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
15
Amp Assign Cus-
tom (Case2)
g.A15a
g.A15b
A25:CUSTOM2
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : MULTI CH STEREO
Amp assign : Custom
Floor Layout : 5ch&SB
Height Sp : 6ch
Dolby Sp : None
Height Layout : Front Height/Top Middle/Rear Height
Speaker Select=Floor & Height
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
Setting
Front Terminal : Center
Surround Terminal : Surround
S.Back Terminal : Center
Height1 Terminal : Front Height
Height2 Terminal : Rear Height
Height3 Terminal : Top Middle
・ Analog input ⇒ Speaker output
(Front L/R (Center), S.Back L/R (Center))
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
16
Amp Assign Cus-
tom (Case3)
g.A16a
g.A16b
A26:CUSTOM3
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : MULTI CH STEREO
Amp assign : Custom
Floor Layout : 5ch&SB
Height Sp : 6ch
Dolby Sp : None
Height Layout : Front Height/Top Middle/Rear Height
Speaker Select=Floor & Height
MAIN ZONE : ON
ZONE2 : ON
ZONE3 : ON
Setting
Front Terminal : ZONE2
Surround Terminal : ZONE3
S.Back Terminal : L : ZONE2 (U3219 10pin)
R : ZONE3 (U3219 11pin)
Height1 Terminal : L : ZONE2 (U3220 10pin)
R : ZONE3 (U3220 11pin)
Height2 Terminal : ZONE2
Height3 Terminal : ZONE3
・ Analog 入力 ⇒ Speaker 出力
(Front L/R (Zone2), Surround L/R (Zone3), S.Back L/R (L:Zone2L / R:Zone3R), Height1 L/R
(L:Zone2L / R:Zone3R), Height2 L/R (Zone2), Height3 L/R (Zone3))
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
155

Denon AVR-X8500H Specifications

General

Channels	13.2
Power Output	150W per channel (8 ohms, 20Hz-20kHz, 0.05% THD)
Frequency Response	10Hz-100kHz (+1, -3dB)
HDMI Inputs	8 (1 front)
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
HEOS Multi-room	Yes
Wi-Fi	Yes
Bluetooth	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Impedance	4-16 ohms
HDR Compatibility	HDR10, Dolby Vision, HLG
Audio Return Channel (ARC)	Yes
Digital Audio Inputs	2 Optical, 2 Coaxial
Analog Audio Inputs	6
Phono Input	Yes
Speaker Connectors	Binding Posts
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Surround Sound Support	Dolby Atmos, DTS:X, Auro-3D
Tuner	AM/FM
Input Sensitivity/Impedance	200 mV / 47 kohms
HDCP Support	2.2
Other Connections	USB, Ethernet, RS-232C
Wireless Connectivity	Wi-Fi, Bluetooth
Signal-to-Noise Ratio	102 dB
DAC	AKM AK4490EQ (32-bit/192kHz)
Total Harmonic Distortion	0.05% (20Hz - 20kHz, 150W)
