Denon DCD-3520 - Player Operation and Remote Control; Playback and Output Controls

Program/Direct Button (PROG/DIRECT)
e¢ Press this button when you want to enter tracks for program-
med playback. (Refer to page 8 for details.)
+10 Button (+10)
e Press this button first when selecting track numbers over 10.
Use it together with the number buttons. For example, to select
track number 15, press [+10 ] then [5].
For track number 33, press [+10 | three times, then press [3].
Number Buttons (1, 2, 3, 4, 5, 6, 7, 8, 9 and 0)
e Use these buttons for the direct search, time search and
program memory functions.
For direct search, press for example button [3] if you want to
hear track number 3. For track number 12, press [_+10_] then [2]
To program tracks, press the PROG/DIRECT button to set the CD
PLAYER into program mode.
Eley Button ( >» PLAY)
Press this button to start playback of a disc.
¢ When this button is pressed, [> PLAY] is displayed, and the
track number being played is displayed together with the
elapsed playback time of the track.
e Tracks are shown on the calendar display. Once a track has been
played, the corresponding track number goes out on the
calendar display.
e With the time search function, playback can be started from
specified point on the disc.
Pause Button ( Il PAUSE)
e Press this button to stop playback temporarily.
e If this button is pressed during playback, playback is stopped
temporarily, the indicator goes out and the
indicator lights.
e Press this button or the play button ( ® PLAY) again to continue
playback.
Step Button ( HM STOP)
Press this button to stop playback.
The disc will stop rotating, and the number of tracks and total
playing time of the disc are displayed in the TRACK NO. and
TIME displays, respectively.
e In case programmed playback is engaged when this button is
pressed, the number of tracks and total playing time of the
program are displayed.
Time Mode Button (TIME)
e This button is used to select the desired indication in the TIME
display. The indication of the display will change each time the
button is pressed.
Normally, the elapsed playback time of the current track is
displayed.
Pressing the button once, is displayed and the
remaining time of the current track is displayed.
Pressing once more, is displayed, and total playing
time of remaining tracks is displayed. However, when program-
med play ts in progress, the total remaining time of the program
is displayed.
Press the button once again to return to the normal display of
the elapsed playback time of the current track.
Display Button (DISPLAY)
e Press this button (DISPLAY) during playback to turn the
indicators on the display window off.
© When pressed once during playback, only the track number
TRACK index number LINDEX ], and playing time
JIME_] will remain lit, and when pressed again, all indicators
are turned off. To set back to the normal display, press either the
DISPLAY) button, the (PROGRAM/DIRECT) button, or the time
search button.
@ When pressed once in the stop mode, the track number
TRACK J, index number LINDEX ], and playing time
[TIME ] are displayed, and when pressed again, only the track
number |_ TRACK ] remains lit.
~)
oe
@
Digital Output Switch (DIGITAL OUTPUT)
e Use this switch to turn the signals from the digital output
terminals (DIGITAL OUTPUT) on and off.
e When off, no digital signals are present on the output.
Volume Control (LINE OUT)
« Use this to adjust the output /evel (volume) of the headphones
or the line output (VARIABLE}
e The same operation is possible using the included remote
control unit (RC-213)
Headphones Jack (PHONES)
e For private listening, you can connect your headphones to this
jack (PHONES). Do not raise the volume level too much when
listening through headphones. (Headphones are sold separ-
ately.)
Door Open Knob
e Press to open the door.
Trap Door
e Opens by pressing the door open knob. To close, press the right
side of the door gently.
Output Terminal (FIX-VARIABLE)
e Connect these jacks to the input jacks on your amplifier. (Refer
to page 6 for details on the connections.)
Output Terminals (BALANCED TYPE)
These cannon type connectors are balanced outputs with an
output impedance of 6000. Connect them to the balanced input
terminals on the amplifier.
e Cannon connector signal layout
(Rear nal terminals ... see Page 4-@)
sy Pin 1 — common
(s 5 é | Pin 2 - cold
Ko Pin 3 -— hot
e Connector: Cannon type XLR-3-32
NOTE: Do not short-circuit the hot or cold pin with the common
pin.
Digital Output Terminals (COAXIAL-1, COAXIAL-2)
e These terminals supply digital data.
e Use the included RCA pin cords or 759 pin cords (available in
stores) for connecting.
Digital Output Terminal (OPTICAL)
e This terminal outputs digital data optically.
¢ Signals are output when the (DIGITAL OUT) switch is at the 1, 2,
or 142 positions.
Continuous Operation
{f the automatic search reverse button @, the automatic search
forward button @, or the +10 button @ are held in, the function of
that button will be repeated.
