Denon DCD-3520 - Disc Loading and Handling; Disc Loading Procedure; Normal and Advanced CD Playback; Normal Playback and Track Search

f
is
OPENING
AND
CLOSING
THE
DISC
HOLDER
AND
LOADING
A
DISC
ree
Shes
—_
Opening and closing the disc holder (This operation only works while the
power is on.)
1. Press the power switch (POWER) to turn on the power
2. Press the open/close button ( & OPEN/CLOSE).
How to load a disc
e Make sure the disc holder is completely open.
e Hold the disc by the edges and place it on the disc tray. (Do not touch
the signal surface, i.e., the glossy side.)
e When using 12 cm. diameter discs, make sure the outer edge matches
the tray guide circumference (Fig. 1), and when using CD singles (8 cm.
diameter) match the outer edge with the inner tray guide circumfer-
ence. (Fig. 2)
e Press the open/close button ( a OPEN/CLOSE) to close the disc
holder.
e When the disc is loaded, the total number of tracks is indicated in the
TRACK display, the total time is indicated in the TIME display, and the
numbers in the calendar light up to the total number of tracks.
e@ When the disc holder is open and a disc is loaded, you may also press
the play ( ® PLAY) or pause { il PAUSE) button to close the disc holder.
(If the play button ( ® PLAY) is pressed, playback will start immediately
upon the disc contents having been read.)
Disc holder open/close button
Tray guide for 8 cm disc
@ cm disc
ICD single}
Caution:
e If your finger should get caught in the disc holder when it closes, press
the open/close button ( & OPEN/CLOSE).
* Do not place any foreign objects on the disc tray, and do not place more
than one disc on the tray at a time. Otherwise malfunction may occur.
¢ Do not push in the disc tray manually when the power is off as this may
cause a malfunction and damage the CD player.
NORMAL CD PLAYBACK ewe '
(1) Starting Playback
Sat boaiat te be = ~ PLAY
00 (> )
Oc1M0O dogooo0anod 96
I
1 Press the power switch (POWER) to turn on the power.
2 Load the disc you want to play.
e When the disc holder is closed, the disc is read and the number of
tracks and total playing time of the disc are displayed.
3 Press the play button ( ® PLAY).
(2) Stopping Playback
x
( Mi STOP)
1 Press the stop button ( @ STOP).
e When all tracks have been played on a disc, playback will stop by itself.
NOTE:
e if no disc is loaded or if the disc is loaded upside*down, “20" appears
on the TRACK display, then the entire display window changes to
“90220000",
TRACK ae
om nA AAA
LURE tts
ee
e ifthe data at the innermost section of the disc cannot be read properly
due to scratches, dirt, etc., the display window will be as shown below.
lf this happens, the search operation may take more time than usual.
7
ae
Yon
UML ls
US aS 8 9 2D
Normal Data cannot be read properly
ADVANCED CD PLAYBACK
(1) Playing a Specific Track Direct Search ..............00
O00 ooogoonnnon «0 @ OD
I
(Number button)
e Use the number buttons and the +10 button to input the number of the
desired track.
For example, to play track number 4, press [4], and to play track number
12, press and [2]. Playback will begin from that tract.
[2] Advancing to the next track
during playback
Press the Automatic search forward button ( PPI) during playback.
« The pickup will advance to the beginning of the next track and plwyback
will continue. Pressing the button several times will forward thepickup
to the corresponding number tracks.
