Denon DCD-720AE - BLOCK DIAGRAM

BLOCK DIAGRAM
49
WXD-8210D
MOTOR DRIVE
IIP4001CRLTF
INTERPION
F,B,D,A,C,E
LOADING+/-
FC+/-, TR+/-
SLED+/-
SPINDLE+/-
DMO/TRO
TC94A92FG
IPOD
USB DEVICE
CURRENT
LIMITER
D+/D-
CD DSP
USB_POWER ON
APPLE
AUTHENTICATION
CVICPV112IPOD20C
I2C CLK/DATA
USB DECODER
TMP92FD28AFG
Tx/Rx
3.3V
3.3V
5V
1.5V
9MHz
Main Clock
TOSHIBA
TOSHIBA
USB JACK
I2S
AUDIO DAC
TI
*DCD720AE : PCM5142
BCK, LRCK, DATA
OP AMP
NJM2068
OP AMP
NJM4556AL
HEADPHONE
AUDIO
OUT
OPTICAL
OUT
SPDIF OUT
AUDIO L
AUDIO R
JRC
JRC
/IPHONE
FOO/FMO
CD MECHANISM
KOTY
CFL16ST103GINK
FUTABA
VFD
MAIN MCU
TMPM330FWFG
TOSHIBA
9MHz
Main Clock
REMOTE
OPSW/CLSW/INSW
OPEN/CLOSE/MUTE
BUS0~3 / BUCK / CCE / RST
MCLK
16.9344MHz
DAC CONTROL (DAC RST/DAC CS/DAC MDT)
buffer
LFP
I2S
IN
OUT
FRONT
IR
*DCD520AE : PCM5102
DCD720AE ONLY
DCD720AE ONLY
DCD520AE ONLY
MUTE
NCP380HMU15AATBG
IR FLASHER
