PARTS LIST OF EXPLODED VIEW DCD520AE
z
Parts indicated by "nsp" on this table cannot be supplied.
z
z
Parts indicated by the "
★
" mark are not illustrated in the exploded view.
z
NOTE:
Ref. No. Part No. Part Name Remarks Q'ty New
- nsp 1 *
C1 - - - -
C9 - - - -
C8 - - - -
C5 - - - -
C12 - - - -
C13 - - - -
C14 - - - -
C10 nsp 1 *
M1 943402102520D SP 1
M1 943402102530D 1
P1 943443100560D SP CGW1A525G45 1 *
P1 943443100570D 1 *
P16 00D9430189903 CGL1A254 1
M2 42141002300AD SP 1 *
M2 42141002301AD 1 *
M9 00D9430179609 SP 1
M9 00D9430179502 1 *
P3 943416100750D 1 *
P4 943415100320D CGR1A540 1 *
M6 nsp 1
M6 nsp 1
P5 nsp 4
P6 nsp CHG2A289 4
C6 943302100130D 1 *
z
C11 00D9430180407 1
z
C11 943611006700S 1
P9 nsp CHR1A028 1
z
C7 943101006510D 1
M7 943401100700D SP 1 *
M7 943401100710D 1 *
P2 943411101840D SP 1 *
P2 943411101890D 1 *
P11 00D9430094700 CHG1A113 3
P7 nsp 1
P11 nsp CHG1A541 2
P8 nsp CMH1A333 1
P8 nsp CMH2A333 1
P13 nsp 1
P10 nsp 1
M4 nsp CUA6A269 1
M3 nsp CMD1A468 2
M5 nsp CMD1A569 6
M8 nsp CMD1A387 2
