Denon DCD-720AE - LEVEL DIAGRAM

51
DCD720AE/DCD520AE
<INPUT> I
C21
CD 1KHz, 0dB TC94A92FG I
C64 IC82 L OUT
USB 1KHz 0dB 720AE : PCM5142PWR NJM2068 R OUT
Sinewave I
C65
520AE : PCM5102PWR
R
881
R8 82
R7 79
R7 80
IC71
NJM4556AL
D
CD7 20AE On ly
+20dB : Analog Signal (Headphone)
: Analog Signal (Line Out)
+10dB : Digital Signal (I2S) +5dB
+6dB DAC GAIN L OUT 2.0V
0dB(2V) +6dB -9.5dB R OUT 2.0V
-6dB
-10dB
P
HONES 1.1V
HP AMP GAIN (32 oh m Te rminate, Vol Max)
-20dB +12dB
DSP
10K
ohm
75 ohm
Res.
47Kohm
Res.
10Kohm
VR.
R
774/ R77
32 ohm
Terminal
PHONES
0.9V
AUDIO DAC
BUFFER
HEADPHONE
AMP
V
R7 1
-7dB
LEVEL DIAGRAM
