11
DHT-390XP
AVR-390
(2) Remove the screws.
Please refer to "EXPLODED VIEW" for the disassembly method of each P.W.B included in HEATSINK MAIN ASSY.
Bottom view
Picture C
Cord holder : Loose
Picture D
Cord holder : Loose
