DN-C615
82 _RST _RESET I Lv - L - Reset signal 'L': RESET
83 Vdd Vdd - - - - - Power supply (+3.3V)
84 P00,D00,AD00 D00 D/O - - Hi-Z - Data bus
85 P01,D01,AD01 D01 D/O - - Hi-Z - Data bus
86 P02,D02,AD02 D02 D/O - - Hi-Z - Data bus
87 P03,D03,AD03 D03 D/O - - Hi-Z - Data bus
88 P04,D04,AD04 D04 D/O - - Hi-Z - Data bus
89 P05,D05,AD05 D05 D/O - - Hi-Z - Data bus
90 P06,D06,AD06 D06 D/O - - Hi-Z - Data bus
91 P07,D07,AD07 D07 D/O - - Hi-Z - Data bus
92 Vss Vss - - - - - GND(0V)
93 P010,D08,AD08,
TM8IOB
PMIX O - Pd L L Deck line out 'H': Mix out of CD+DECK
94 P011,D09,AD09,
TM8IC
PPOFF I - - H - 'L': Power failure detection
95 P012,D10,AD10,
TM11IOA
PDECKM
UT
O - Pd L L Deck line mute 'L': MUTE ON
96 P013,D11,AD11,
TM11IOB
POPEN I - - Hi-Z - OPEN switch
97 P014,D12,AD12,
TM11IC
PCLOSE I - - Hi-Z - CLOSE switch
98 P015,D13,AD13,
TM12IOA
PLOAD O - - Hi-Z H OPEN/CLOSE signal (PWM out put) (During Pnrst='L', out put
PWM(50%))
99 P016,D14,AD14,
TM12IOB
O--Hi-ZH
100 P017,D15,AD15,
TM12IC
PINSW I - - Hi-Z - Inner circle SW
Pin
No.
Pin Name Symbol I/O Det Ext Res Ini Function
