PARTS LIST OF EXPLODED VIEW
zParts for which "nsp" is indicated on this table cannot be supplied.
z
P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.
zPart indicated with the mark " ★ " is not illustrated in the exploded view.
zThe parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
Ref. No. Part No. Part Name Remarks Q'ty New
P1 nsp MAIN P.W.B. UNIT ASS'Y 1
P1-1 - I/O A UNIT
P1-2 - I/O B UNIT
P1-3 - POWER UNIT
P1-4 - HP JACK UNIT
P1-5 - JOG UNIT
P1-6 - STB LED UNIT
P2 nsp I/O POWER P.W.B. UNIT ASS'Y E3 1
P2 nsp I/O POWER P.W.B. UNIT ASS'Y E2 1
P2-1 - MAIN UNIT
P2-2 - PANEL MAIN UNIT
P2-3 - PANEL SUB UNIT
002B 402410093106P FRONT PANEL 1 *
004B 443510037106P FRONT CHASSIS 1 *
006B 416510039001P WINDOW 1*
008B 00M238H355020 LENS 1
012B 412510001011P JOG KNOB 1*
014B nsp JOG BRACKET 1 *
020B 412510049006P KNOB 2*
022B nsp HP BRACKET 1 *
024B nsp NUT 1
030B 411510109004P RUBBER BUTTON 1 1 *
032B 411510110004P RUBBER BUTTON 2 2 *
034B 415510020004P DOOR 1*
036B 00M49AS112010 SHAFT 2
038B 00M2912259020 ACCESSORY 1
040B nsp LCD HOLDER 1 *
044B 00M43BS270050 POWER BUTTON 1
002D 00M43BS257010 TOP COVER 1
003D nsp INSULATOR 1
004D 00M340V107010 SHEET :IO CASE 2
010D nsp HANDLE 2
★
014D nsp LABEL N CAUTION E3 1
★
015D nsp LABEL CANADA ICES-003 E3 1 *
★
016D nsp C-UL LABEL E3 1
★
018D nsp LABEL XLR 1
★
020D nsp LABEL SUB ASSY E3 E3 1
★
020D nsp LABEL SUB ASSY E2 E2 1
002G nsp MAIN CHASSIS 1 *
004G 00M416H057010 LEG 4
016G 00M371K010020 SCREW 1
018G 00M54050400R0 SCREW 1
019G nsp LINK 1
★
020G nsp EARTH LABEL E2 1
★
022G nsp L=36 3.1D DIP COARTING CLAMPER 2 *
Ref. No. Part No. Part Name Remarks Q'ty New
★
024G nsp CORD HOLDER (L50) 3
★
026G nsp WIRE CLAMP BAND 5
030G nsp WASHER 1
902G nsp NUT 1
★
910G nsp LABEL U CAUTION E3 1
★
910G nsp LABEL N CAUTION E2 1
AC300 00D2033983008 AC INLET 1
★
CW001 nsp UL TUBE (4.7) CLEAR 2
CW011 nsp SRA-UL1015 AWG18 L=9CM 1
★
CW012 nsp LUG - BARA UL1007 AWG18 BLACK 1
★
CW013 nsp WIRE AWG28 20MM 1 *
★
CW021 nsp VHR 3P-BARA 2P UL1672 AWG22 P-CORD 1
★
CW161 nsp PHR-16/PHR-16 UL1430 AWG24 250MM 1 *
★
CW061 nsp PHR-6/PHR-6 UL1430 AWG24 250MM 1 *
★
CW141 nsp PHR-14/PHR-14 UL1430 AWG24 150MM 1 *
★
CW071 nsp PHR-7/PHR-7 UL1007 AWG26 180MM 1 *
★
CW081 nsp ZHR-8/ZHR-8 UL1571 AWG28 70MM 1 *
★
CW401 606050111006P FFC 40PIN 250MM 0.5PITCH UL2896 1 *
CW142 606050110003P FFC 14PIN 150MM 1.0PITCH UL2896 1 *
CW402 606050112009P FFC 40PIN 100MM 0.5PITCH UL2896 1 *
Z-001 173010009001S OLED ASSY(UEL237) 1 *
Z-002 nsp CR2032 (SANYO) 1
★
Z-003 nsp FERRITE CLAMP(RFC-6W) 1
★
Z-004 nsp FERRITE CLAMP(RFC-9) 1
SCREWS
a nsp SCREW-B(TAPTITE 3x8 B-TYPE BK/BH) 24
b nsp SCREW(M3x6 BK/BH) 17
c nsp +FLAT HEAD SCREW M3X8 BLACK 2
d nsp SCREW(M3x6 BK/FH) 3
e nsp SCREW(TAPTITE 3x8 B-TYPE BK/WBH) 10
f nsp SCREW P-TITE 2X6 2
g nsp SCREW(TAPTITE 3x8 B-TYPE BK/NOTCH BH
）
14
