PARTS LIST OF P.W.B. UNIT
zParts for which "nsp" is indicated on this table cannot be supplied.
zThe parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
MAIN P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 00D2622785905 SN74LV125APWRG4 +C
IC102 00D2622114903 UPD4721GS-GJG +C
IC103 231810011506S BD2041AFJ
IC104 236810084608S S1R72U01F12E300 *
IC105 236810015503S TS3USB221RSER
IC106 00MHC1225209Y NJM2387DL2
IC107 00D2631281908 BD9130NV-E2
IC108,109 00MHC1225209Y NJM2387DL2
IC203 00MHC405321YY BU4053BCFV
IC204-206 00D2630896909 NJM2068MD-TE1 +C
IC207 00MHC405221IZ BU4052BCF-E2
IC208 00D2630896909 NJM2068MD-TE1 +C
IC209 235810042502S NJW1159V *
IC210 00D2630896909 NJM2068MD-TE1 +C
IC211 00MHC405221IZ BU4052BCF-E2
IC212 00D2630896909 NJM2068MD-TE1 +C
IC401 00D2622515900 SN74LV04APW-EL2 +C
IC402 239810035506S PLL1707DBQ *
IC403 00D2622517908 SN74LV08APW-EL2 +REF
IC404 00MHC1023421Z BD45302G RESET 3.0V
IC405 00D2623762008 AK4683EQ
IC406 236810032508S AK4104ET
IC501 8R2461005500P M29W640GB70NA6E
IC502,503 246810031601S W9825G6EH-6J *
IC504 00D2622572901 SN74LVU04APW-EL2 +REF
IC505 241810027607S R5S72631P200FP
IC506 00MHC1003677Z RS5C372A-E2
IC507 246810032505S AT24C128BN-SH-T
IC701,702 234810009502S TC7WH125FU
IC703,704 00MHC1024409Z NJU3716AM-TE1
IC705 00D2622640901 SN74LV245APW-EL2
IC706,707 00D2623694901 SN74LV165APW
TR102 00D2690184907 KRA102S-RTK/P (10K-10K)
TR103,104 00D2690192902 KRC102S-RTK/P (10K-10K)
TR201-203 00D2690192902 KRC102S-RTK/P (10K-10K)
TR204-207 00MHX300012AY 2SC4081 (Q R) 2SC4116 (Y GR)
TR208 00D2690192902 KRC102S-RTK/P (10K-10K)
TR209,210 00D2690088906 DTC114TKT96 +C
TR211 00MBA1211300Y DTA144TE,RN2123,UN9110
TR212 00MHX115861BY 2SA1586 (GR)
TR401 00D2690184907 KRA102S-RTK/P (10K-10K)
TR402,403 00D2690192902 KRC102S-RTK/P (10K-10K)
TR404 00D2690086908 DTA114TKT96 +C
