SAFETY PRECAUTIONS
The
following
check
should
be
performed
for
the
continued
protection
of
the
customer
and
service
technician.
LEAKAGE CURRENT CHECK
Before
returning
the
unit
to
the
customer,
make
sure
you
make
either
(1)
a
leakage
current
check
or
(2)
a
line
to
chassis
resistance
check.
If
the
leakage
current
exceeds
0.5
milliamps,
or
if
the
resistance
from
chassis
to
either
side
of
the
power
cord
is
less
than
460
kohms,
the
unit
is
defective.
*
SPECIFICATIONS
Signal system:
Applicable discs:
S-Video output:
Video output:
Component output:
Audio output:
Audio output properties:
Power supply:
Power consumption:
Maximum external
dimensions:
Weight:
Remote control unit:
Type:
Power supply:
NTSC
(1) DVD/video discs
1-layer
12
cm
single-sided
discs,
2-layer
12
cm
single-sided
discs,
2-layer
12
cm
double-sided discs (1 layer per side)
1-layer
8
cm
single-sided
discs,
2-layer
8
cm
single-sided
discs,
2-layer
8
cm
double-
sided discs (1 layer per side)
(2) Compact discs (CD-DA, Video CD)
12 cm discs, 8 cm discs
Y
output
level:
1
Vp-p
(75
Q/ohms)
C
output
level:
0.286
Vp-p
(For U.S.A. & Canada models)
C output level: 0.300 Vp-p
(For Eutope/Asia/Taiwan R.O.C. models)
Output connector: Pin-plug jacks, two sets
Output connectors: S connectors, two sets
Output level: 1 Vp-p (75 Q/ohms)
Y output level: 1 Vp-p (75 Q/ohms)
Pb
output
level:
0.648
Vp-p
(75
Q/ohms)
Pr
output
level:
0.648
Vp-p
(75
Q/ohms)
(For
U.S.A.
&
Canada
models)
Pr output level: 0.700 Vp-p (75 Q/ohms)
(For Europe/Asia/Taiwan R.O.C. models)
Pb output level: 0.700 Vp-p (75 Q/ohms)
Output connector: Pin jack, one set
Fixed output level: 2 Vrms, 1 set
(1) Frequency response
@
DVDs
(linear
PCM)
:
2
Hz
to
22
kHz
(48
kHz
sampling)
> 2 Hz to 44 kHz (96 kHz sampling)
Variable output level: 0 to 2 Vrms, 1 set
@ CDs : 2Hz to 20 kHz
(2) S/N ratio
@ DVDs : 118 dB
@ CDs : 118 dB
(3) Total harmonic distortion
@ DVDs : 0.0015 %
@® CDs : 0.0018 %
(4) Dynamic range
@ DVDs : 108 dB
@ CDs : 100 dB
(5)
Channel
separation
-
@ DVDs : 110 dB
@ CDs : 110 dB
AC
120
V,
60
Hz
(For
U.
S.
A.
&
Canada
models)
/
AC230
V,
50
Hz
(For
Europe
model)
/
-
AC115/230
V,
50
Hz
(For
Asia/Taiwan
R.O.C.
models)
40
W
434
(width)
x
135
(height)
x
374
(depth)
mm
(not
including
protruding
parts)
16.5
kg
RC-540
Infrared pulse
DC 3V, two SUMS batteries
