Proceeding : REAR MOLD PANEL → SIDE PANEL → TOP PANEL ASSY
→ CD MECHA ASSY → SHIELD COVER → FRONT PANEL ASSY
(1) Removethescrews.

(2) RemovetheconnectorwireandFFC.Removethescrews.
11. FRONT PANEL ASSY
↑Shooting direction: D↑ ↓Shooting direction: C↓
View from the bottom
x4
x2
CN10
CN63
PF11
STYLE PIN
TAPE
x2
