Operation Section

1

–

10

Q001235E

SCV

Plunger A: Finish Compression

Plunger B: Finish Intake

Plunger A: Finish Intake

Plunger B: Finish Compression

Plunger A: Begin IntakePlunger

B: Begin Compression

Plunger A: Begin Compression

Plunger B: Begin Intake

Suction Valve

Plunger A

Plunger B

Discharge Valve

Eccentric Cam

Ring Cam
