Denso CRS - Page 16

Operation Section
1
–
11
Overall System Flow (Fuel)
Q000927E
Supply Pump
(HP3 or HP4)
Plunger
Feed Pump
Delivery
Valve
SCV
(Suction
Control Valve)
Rail
Rail Pressure Sensor
Pressure Discharge Valve
Pressure Limiter
Injector
ECU
EDU
Various
Sensors
Fuel Filter
Fuel Tank
: Flow of Injection Fuel
: Flow of Leak Fuel
