Operation Section
1
–
58
Handling Injectors with QR Codes (Reference)
- Injectors with QR codes have the engine ECU recognize and correct the injectors, so when an injector or the engine
ECU is replaced, it is necessary to register the injector's ID code in the engine ECU.
Replacing the Injector
- It is necessary to register the ID code of the injector that has been replaced in the engine ECU.
Replacing the Engine ECU
- It is necessary to register the ID codes of all the vehicle injectors in the engine ECU.
QD1536E
Engine ECU
Spare Injector
"No correction resistance, so no electrical recognition capability."
* Necessary to record the injector ID codes in the Engine ECU.
"No correction resistance, so no electrical recognition capability."
* Necessary to record the injector ID codes in the Engine ECU.
Q000985E
Vehicle-Side Injector
Spare Engine ECU
To Next Page
