Denver CAD-405 - Location of Parts and Controls

E2
LOCATION OF PARTS AND CONTROLS
1. POWER ON/OFF ( )
2. FUNCTION SELECT BUTTON: BASS/TREBLE/BALANCE/FADER / TA SEEK/MASK DPI/
RETUNE/AUDIO DSP/LOUDNESS/CD MULTI/BEEP/SEEK/STEREO/LOCAL
3. VOL UP/VOL DOWN FOR BASS/TREBLE/BALANCE/FADER / TA SEEK/MASK DPI/RETUNE/
AUDIO DSP/LOUDNESS/CD MULTI/BEEP/SEEK/STEREO/LOCAL
4. PRESET STATIONS (1,2,3,4,5,6)
5. ‘AF’ function (ALTERNATIVE FREQUENCIES)
6. ‘TA’ function (TRAFFIC ANNOUNCEMENT)
7. ‘PTY’ function (PROGRAM TYPE)
8. DISPLAY BUTTON (DISP)
9. MODE BUTTON (MODE)
10. BAND BUTTON (BAND)
11. AUTOMATIC OR MANUAL TUNING
(FREQ UP OR FREQ DOWN )/
CD TRACK/SEARCH BUTTON
12. AUTO SEEK SEARCH TUNING (A/PS)
13. ‘SCAN’ AUTOMATIC TUNING CONTROL (SCAN)
14. MUTE BUTTON (MUT)
15. LCD DISPLAY
16. PANEL RELEASE BUTTON ( )
17. CD SLOT
18. CD EJECT BUTTON ( )
19. PAUSE BUTTON
20. INTRO BUTTON (Preview all Tracks)
21. REPEAT BUTTON
22. RANDOM BUTTON
23, 24. + 10 TRACK SEARCH DOWN/UP
25. USB PORT
26. MULTI-MEDIA CARD (MMC) / SD CARD SLOT
27. FRONT AUX IN
28. RESET BUTTON
29. POWER INDICATOR LED
18 17
141 5 15 16 267 6
12 9 10 13 19 20 21 22 23 24 27 25118
2 3
(1-6)
4
2829
RESET
18 17
141 5 15 16 267 6
12 9 10 13 19 20 21 22 23 24 27 25118
2 3
(1-6)
4
2829
RESET
18 17
141 5 15 16 267 6
12 9 10 13 19 20 21 22 23 24 27 25118
2 3
(1-6)
4
2829
RESET
