GASOLINE CHAIN SAW
EN
EN
Model/Article DS-4516/952367 DS-5218/952377 DS-5820/952387
Number of chain links, pc. 64 72 76
Slot width, mm 1,5
Guaranted sound power level, dB(A) 113
Measured sound power level, dB(A) 111,8 108,6 108,6
Sound pressure level, dB(A) 104,9 101,9 101,9
Uncertainty value of sound power K, dB(A) 3
Vibration level (front handle), m/s 6,254 4,795 4,795
Vibration level (rear handle), m/s
2
6,960 5,247 5,247
Uncertainty value of vibration K, m/s
2
1,5
Dimensions L×W×H, cm 44×26,5×34,5
Weight, kg 6,34 6,46 6,94
PREPARATION FOR OPERATING
Unpacking
At the time of purchase, your chainsaw is shipped to you in a cardboard shipping box with special protective
features inside to protect it during shipment.
To remove the tool from the carton, remove the packing tape, open the carton and carefully remove the
accessories carefully.
WARNING!
Always check the complete set and technical condition of the product after unpacking and
transportation.
Keep the packing materials in case you need to transport the unit.
Assembly requirements
Before you start up your chainsaw for the rst time you must assemble the bar and chain, adjust the chain, ll
the fuel tank with fuel and add oil to lubricate the chain.
Warning! Do not START the chain saw until it is completely set up for use.
Read this manual carefully before using the machine. Pay particular attention to safety precautions. This
manual is a reference and instruction manual and provides general information on the assembly, operation
and maintenance of the chainsaw.
Drive bar and saw chain assemble
WARNING!
Always wear protective gloves when working with the chain.
1. Make sure that the device is turned o. Place the saw on a at surface.
2. Move the chain brake shield to the operating position by pulling the lever toward you. Make sure the
chain rotates around the bar (g. 4).
3. Unscrew the two nuts (A) securing the bar and chain guard. Remove the protective cover together with
the chain brake shield (B) (g. 5).
