18
GASOLINE CHAIN SAW
EN
EN
A B
Fig. 16
When the diameter of the trunk is greater than the length of the bar, two cuts are made, as shown in g. 17.
Fig. 17
WARNING!
During the nal cut, if the chainsaw approaches the uncut part of the trunk, the tree will begin to fall.
When the tree begins to fall, remove the chainsaw from the cut, stop the engine, place the chainsaw on the
ground, and leave the area of the intended escape route. Perform all actions promptly, without delay.
Branch pruning
WARNING!
Do not trim branches while standing on the trunk. It may result in serious injury.
Branches are cut from the fallen tree. Do not cut branches that support the trunk and keep it from rolling
away (A) until you have cut the trunk (g.18).
Branches subject to external loads should be cut from the bottom up to prevent the chainsaw from jamming.
Fig. 18
