11
2.3 Connection Strip on ME5000
IMPORTANT
If an external rotary-type transducer is used, an external power supply has to
be connected to the measuring instrument (see next page).
Piezo-Transducer Strain Gauge- and/or
exte
nal Rotar
y Transducer
