10 Measuring Ranges
Select from 6 measuring ranges. Each measuring range is dynamically matched to the
input calibration value ( K-WERT ). All measuring ranges are rounded-up or rounded-
down.
Measuring ranges if calibration value = 200:
Measuring Range 1: 8 – 48 N cm
Measuring Range 2: 40 – 240 N cm
Measuring Range 3: 80 – 480 N cm
Measuring Range 4: 4 – 24 N m
Measuring Range 5: 8 – 48 N m
Measuring Range 6: 40 – 240 N m
Calculate MBA: Measuring Range / (calibration value * 2)
Example 1 Measuring Range 1:
20 pC / (72 pC/N m * 2) = 0.058 N m 0.058 N m * 100 => 6 N cm
Example 2 Measuring Range 4:
1000 pC / (172 pC/N m * 2) = 2.90 N m 2.9 Nm => 3 N m
Calculate MBE: MESSBEREICH * 5 / (K-WERT * 1.1)
Example 1 Measuring Range 1:
20 pC * 5 / (172 pC/N m * 1.1) = 0.52 N m 0.52 N m * 100 = 50 N cm
Example 2 Measuring Range 4:
1000 pC * 5 / (172 pC/N m * 1.1) = 26.42 N m 26.42 N m => 20 N m
If the measured value is larger than the measuring range, then the display shows OVL
(overflow).
To Example 1 Measuring Range 1:
MB1 X = 100pc / K-Wert MB1 = 100 pc MB4 = 5000 pc
MBA = X x 0,08 MB2 = 500 pc MB5 = 10000 pc
MBE = X x 0,96 MB3 = 1000 pc MB6 = 50000 pc
11 Disposal
Completely disassemble the instrument prior to disposal. Sort all materials and dispose
them in accordance with local environmental regulations.
