LOGPLACEMENTFORP325(B)/
VP325(B)MODELS
1. Place rear log onto grate making sure
notches rest over grate (see Figure 27).
2. Place front right log onto front right side
of grate with back of log tting into notch
on right front of rear log (see Figure 27).
3. Rest front of front left log between rst two
grate ngers on left of grate assembly and
rear into notch on left front of rear log (see
Figure 28).
4. Place top of log 4 into notch on log 1. Rest
log 4 on the center of grate as shown in
Figure 29.
5. Place top of log 5 into notch on top right
of log 1 (see Figure 29). Rest log 5 be-
tween two middle grate ngers as shown
in Figure 30.
To enhance the look of the hearth you may
optionally place the lava rock provided around
the front and sides of the burner.
NOTICE: Do not put lava rock
insidetheburnerpanoraround
theairmixertting.Placinglava
rock inside the burner pan or
blocking the openings of the
propane/LPair-mixercouldcause
performanceproblems.
INSTALLATION
Continued
Figure 27 - Installing Logs 1 and 2
Rear
Log
Front
Right Log
Figure 29 - Installing Logs 4 and 5
Figure 30 - Logs Installed
Top Log
Top Y-Log
Rear Log
Front Left
Log
Figure 28 - Installing Log 3
Front
Left Log
Rear Log
