EN Product Information
03/2020 5 / 84
mm in.
A 227 8.94
B 90 3.54
C 222 8.74
D 210 8.28
E 215 8.46
F 390 15.35
CONNECT-X
mm in.
A 227 8.94
B 90 3.54
C 222 8.74
D 210 8.28
E 215 8.46
CAD files
For information about the dimensions of a product, see the Dimensional drawings archive:
