6. I/O CONNECTIONS
An I/O connector with 10 pins is set up on the
rear panel of the controller.
6.1. Input
Pin Function Comment
1 COM 0VDC Common pin for all input signals; the signal must be taken between the pin
1 (0 VDC) and the other pins (2,3 and 4)
2 START Remote start of the unscrewing cycle.
Right step tightening with a stop at the torque.
3 REVERSE Remote start of the untightening cycle. No control of the torque reached.
4 STOP Motor stop, "EXTERNAL STOP" displayed on the screen, the motor stops
and starts after the contact opening.
5 NOT USED Not used
6.2. Output
Pin Function Comment
6 TORQUE Torque reached signal. 24 V-20 mA, max 0.5 W
7 LEVER Lever start up signal when the lever is pressed or a "START" signal is
transmitted. No signal during the untightening.
24 V-20 mA, max 0.5 W
8 ERROR Error signal is actuated when
- The torque is reached during the "slow start" phase
- The torque is reached during the "approach speed" phase
- The selected tightening time has elapsed without having reached the
torque
24V 20mA,max 0.5W
9 COM0VDC Common pin for all output signals; the signal must be taken between the
pin 9 (0 VDC) and the other pins (6,7 and 8)
10 NOT USED Not used
The output signals are protected.
An overload or a short circuit on the
signals triggers the controller to stop. To
reset the signals, you must turn o the
controller for a minimum of 6 seconds,
check the connectors and then start up
again.
