1.5.3. Power
If the line voltage for your LAC-6 Series Oven varies more than 10% from the oven
voltage rating, electrical components such as relays and temperature controls may operate
erratically.
If the line voltage is lower than the oven voltage rating, heat-up time may be
significantly longer and motors may overload or run hot
If the line voltage is higher than the nameplate rating, motors may run hot and draw
excessive amperage
Model
Volts
Amps
Hertz
Phase
Heater
KW
Cord and Plug
LAC 1-10-6
120
10.0
50/60
1
1
Included, 15 Amp (NEMA 5-15)
LAC 1-38A-6
120
16.5
50/60
1
1.6
Included, 20 Amp (NEMA 5-20)
LAC 1-38B-61F
†
240
9.5
50/60
1
1.8
Included, 15 Amp (NEMA 6-15)
LAC 1-67-6†
240
12.0
50/60
1
2.4
Included, 15 Amp (NEMA 6-15)
LAC 2-12-6† 2F
‡
240
18.5
50/60
1
3.6
None, Hardwired
LAC 2-18-6†
‡
240
23.5
50/60
1
4.8
None, Hardwired
†
The LAC Series Oven designed for 240 volts (see oven nameplate) will operate satisfactorily on a
minimum of 208 Volts, but will result in 25% reduced heater output. If your power characteristic is lower,
contact Despatch Industries. An option is available to regain the full heater power when operating on 208V.
‡
The LAC 2-12 and LAC 2-18 must be hardwired to the electric supply using 10 AWG or larger wires
suitable for at least 75 °C (167 °F).
