1.5. Specifications
1.5.1. Dimensions
LAC
Model
No.
Chamber Size
in (cm)
Capacity
feet
3
(liters)
Overall Size
in (cm)
Max.
Number of
Shelf
Positions
Exhaust Diameter
Located on Back
of Chamber
in (cm)
W0F
*
D
H
W
D
H
1-10
13.75
(35)
12
(28)
12
(31)
1
(33)
23
(58)
19
(48)
29.5
(75)
5
1
(2.5)
1-38A
18.75
(48)
18
(46)
19
(48)
3.7
(105)
28
(71)
25
(64)
35.5
(90)
9
2½
(6.4)
1-38B
18.75
(48)
18
(46)
19
(48)
3.7
(105)
28
(71)
25
(64)
35.5
(90)
9
2½
(6.4)
1-67
23.75
(60)
20
(51)
24
(61)
6.6
(187)
36
(91)
27
(69)
40.5
(103)
11
2½
(6.4)
2-12
23.75
(60)
24
(61)
36
(91)
12
(340)
36
(91)
31
(79)
52.5
(133)
17
2 x 2½
(6.4)
2-18
35.25
(91)
24
(61)
36
(91)
18
(510)
47
(119)
29.5
(75)
52.5
(133)
17
2 x 2½
(6.4)

The LAC-6 oven is not intended to process solvents or other
volatile or flammable materials. Oven exhaust is intended for
cooling purposes only.
*
Allow 0.375" (0.95 cm) clearance on each side for shelf supports (3/4 in (1.9 cm) total).
Warning!
Do not place this oven in an environment harmful to electrical
components.
Placing this oven in an environment detrimental to electrical
components (for example, environments where carbon fibers,
coal dust or similar contaminants may be present) may result
in component failure.
Contact Despatch for options available to help prevent such
failures.
