Basic Setup
ANALOG AUDIO INPUTS
Using a cable ending with two standard RCA jacks connect DB91-RX analog signal outputs to
the analog audio inputs of your equipment.
WARNING: Do not exceed maximum input level. This may permanently damage the device.
DIGITAL AUDIO INPUTS
Using a cable ending with a standard RCA jacks connect DB91-RX S/PDIF output to the digital
audio input of your equipment.
NOTE: As only one input can be managed by the encoder at certain point of time, please select
the preferred signal source input – either analog or digital one. Selecting the preferred input can be
performed under CONFIGURATION menu (see “IP Audio” on page 20).
LAN PORT
For normal operation it is necessary the device to be connected to a local network or Internet
by cable with RJ-45 connector.
