WEB Interface
DB91-RX is controlled trough a build in WEB Server and a standard web browser can be used
to monitor its status or to make some adjustments. To operate the device you need to know its IP
Address. In case you are not aware of it, you can hear it through the headphones when you turn on
the the device. Alternatively, use the Network discovery feature at Local networks. Then open a
new WEB Browser and enter the device IP address in the address eld then press [Enter].
NETWORK DISCOVERY
This is a network setting that denes whether your computer can see (nd) other computers and
devices on the network and whether other computers on the network can see your computer. By
default, Windows Firewall blocks network discovery but you can enable it.
1. Open Advanced sharing settings by clicking the Start button, and then on “Control Panel”.
In the search box, type “network”, click “Network and Sharing Center”, and then, in the left
pane click “Change advanced sharing settings”;
2. Select your current network prole;
3. Click Turn on network discovery, and then click save changes.
NOTE: If you’re prompted for an administrator password or conrmation, type the password,
provide conrmation or contact your system administrator.
If you have already enabled this function on your computer DB91-RX will be automatically
added to the Device list section. The device will be ready for usage and no additional adjustments
will be required except user name and password.
ACCESS
DB91-RX provides you with a protected access to the device settings. To make the necessary
adjustments to the device, please log in as an ADMINISTRATOR. The default values being
username: admin, password: pass.
