ineo 223/283/363/423 1-33
1.14 Control panel
1
d Reference
For details, refer to chapter 4 of the [User’s Guide Copy Operations].
10 [Proof Copy] key Press this key to print a single proof copy to be checked before
printing a large number of copies. You can also display a finish-
ing image using the current settings in the touch panel. This
function is available only when a hard disk is installed.
11 [Start] key Press to start the copy, scan or fax operation.
12 Data indicator Flashes in blue while a print job is being received. Lights up in
blue when a print job is queued to be printed or while it is being
printed. Lights up in blue when there is saved fax data or un-
printed fax data.
13 [C] (clear) key Press to clear a value (such as the number of copies, a zoom
ratio, or a size) entered using the keypad.
14 Keypad Use to type in the number of copies, zoom ratio, fax number
and various other settings.
15 [Guidance] key Press to display the Guidance screen, which can be used to
display descriptions of the various functions and details of op-
erations on the screen.
16 [Enlarge Display] key Press to enter Enlarge Display mode. If authentication is per-
formed with Authentication Manager, it does not enter Enlarge
Display mode.
17 [Accessibility] key Press to display the screen for specifying settings for user ac-
cessibility functions.
18 [Access] key If user authentication or account track settings have been ap-
plied, press the [Access] key after entering the user name and
password (for user authentication) or the account name and
password (for account track) in order to use this machine.
19 [Brightness] dial Use to adjust the brightness of the touch panel.
20 [User Box] key Press to enter User Box mode. While the machine is in User
Box mode, the indicator on the [User Box] key lights up in
green.
21 [Fax/Scan] key Press to enter Fax/Scan mode. While the machine is in
Fax/Scan mode, the indicator on the [Fax/Scan] key lights up in
green.
22 [Copy] key Press to enter Copy mode. (As a default, the machine is in Copy
mode.) While the machine is in Copy mode, the indicator on the
key lights up in green.
No. Part Name Description
