Website: www.devicewell.com Email: support@devicewell.cn 10
HDS7105
5.4 Parameters
Name
4*HDMI+1*DP Switcher
Model
HDS7105
Video Signal
Input
Input signal
HDMI/DP video signal
Rate
270Mbps~3Gbps
Connector
Standard
Reflection loss
>15dB 5MHz~3GHz
Signal amplitude
800mV±10%(SDI/HDMI)
Impedance
100Ω (HDMI) 75 Ω(SDI)
Balance
Adaptive
DVD input HDMI support
480i/576i,480p/576p,720p,1080i,1080p,
Computer HDMI input
support
1920x1080,1680x1050,1600x900,1440x1050,1366x768,1360x768,1360x768,1280x10
24,1280x960,1280x800,1280x768,1280x720,1280x600,1152x864,1024x768,800x600,
Video Signal
Output
output signal
HDMI video output
Code rate
270Mbps~3Gbps
Connector
Standard
Return Loss
>15dB 5MHz~3GHz
Signal amplitude
800mV±10%(SD /HDMI)
impedance
100Ω (HDMI) 75 Ω(SDI )
DC offset
0V±0.5V
Clock recovery
Support
Control
Parameter
Control
9600 baud, 8 bits, 1 stop bit, no parity
Connection
15-pin D-port, 2-RX, 3-TX, 5-GND
Network control
RJ45,100M
General
Parameter
power supply
12V/DC
Power rate
18w
control panel
Support on-site production, integration of a variety of buttons.
Operating temperature
0~50, No condensation
Storage temperature
-20~75
Working humidity
20%~70%RH
Storage humidity
0%~90%RHNo condensation
