27
LT-2023
FIGURES, DIAGRAMS AND PARTS LIST
PART DESCRIPTION
525DS
"N" SERIAL #
525DS-Q
"R" SERIAL #
Flow Meters:
29 Standard Flow Meter 505DZ-607 505DZ-607
30 Low Output Meter 515LF-607 515LF-607
31 Foam Kit N/A N/A
32 Fuse (For PC Board) 515ADZ-627 515ADZ-627
Hoses:
33 1/8" ID (Blue) (4' Lg) 444-554 444-554
34 1/2" ID PVC Braided (4' Lg) 444-549 444-549
35 1/2" ID Silicone Braided (2' Lg) 505DZ-634 505DZ-634
Hose Clamps:
36 Plastic (1/4" ID Hose) N/A N/A
37 Ladder Clamp (1/2" ID Hoses) 444-566 444-566
38 Hour Meter PV5LD-617 PV5LD-617
39 Intake Canister N/A 525DD-614
40 Light Panel / Ribbon Cable 525D-615 525D-615
41 Purge Manifold Assembly 525DD-617 525DD-617
42 Motor Mounts 505IZ-609 505IZ-609
43 Oxygen Outlet Port 525DD-606 525DD-606
44 PC Board 525DD-622 525DD-622
45 Power Cord w/Strain Relief PV5LD-618 PV5LD-618
46 Power Cord Strap MC29D-657 MC29D-657
47 Power Cord Strain Relief 505DZ-645 505DZ-645
48 Power Switch 505DZ-508 505DZ-508
49 Pressure Regulator MC29D-612 MC29D-612
50 Pressure Relief Valve 515ADZ-614 515ADZ-614
51 Rotary Valve 515ADZ-702 515ADZ-702
52 Sieve Bed 525D-619 525D-619
Wire Harness:
53 Communication Harness/Port N/A N/A
54 Main Harness 525DD-623 525DD-623
55 Rotary Valve Harness 525D-621 525D-621
525DS Unit - Serial # "N" (115V Units with Auxiliary Oxygen Port)
525DS-Q Unit - Serial # "R" (115V Units with Auxiliary Oxygen Port)
