DeVilbiss 525DS-Q - Page 34

LT-2023
34
FIGURES, DIAGRAMS AND PARTS LIST
PART DESCRIPTION
525PS
"F" SERIAL #
525PS
"J" SERIAL #
1 Accumulator Tank 525D-610 525D-610
2 Auxiliary Oxygen Port N/A N/A
Cabinet Parts:
3 Base 525K-603 525KD-603
4 Bib 525D-604 N/A
5 Communication Port Door 525D-640 525DD-640
6 Compressor Box 525D-605 525DD-605
7 Filter Door 525D-639 525DD-639
8 Front Cover 525D-601 525DD-601
9 Rear Cover 525D-602 525DD-602
10 Cabinet Screw (Original) 525DD-628 525DD-628
11 Cabinet Screw (plastite) N/A N/A
12 Cable Tie, (Sieve Bed) 505DZ-617 505DZ-617
13 Capacitor (Motor Start/Run) 525K-616 525K-616
14 Caster, Non-locking 501DZ-603 501DZ-603
Check Valves:
15 Bed Check Valve PVO2D-607 PVO2D-607
16 Final Check Valve PVO2D-607 PVO2D-607
17 Circuit Breaker 515KZ-615 515KZ-615
18 Cooling Fan 515UK-634 515UK-634
19 Cooling Fan Guard N/A N/A
20 Compressor 525PS-625 525PS-625
21 Compressor Rebuild Kit 525K-643 525K-643
22 Exhaust Mufer 515A-705 515A-705
Filters:
23 Cabinet Air Filter 303DZ-605 303DZ-605
24 Intake Bacteria Filter MC44D-605 MC44D-605
25 Compressor Filter (Plastic) 525D-622 525D-622
26 Compressor Filter (Sintered Bronze) N/A 525DD-626
27 Final Bacteria Filter PV5LD-651 PV5LD-651
Fittings:
28 Accumulator Tank "Tee" 444-582 444-582
Flow Meters:
29 Standard Flow Meter 505DZ-607 505DZ-607
30 Low Output Meter 515LF-607 515LF-607
31 Foam Kit 525D-600 N/A
32 Fuse (For PC Board) 515AKZ-610 515AKZ-610
Hoses:
33 1/8" ID (Blue) (4' Lg) 444-554 444-554
34 1/2" ID PVC Braided (4' Lg) 444-549 444-549
35 1/2" ID Silicone Braided (2' Lg) 505DZ-634 505DZ-634
Hose Clamps:
36 Plastic (1/4" ID Hose) N/A N/A
37 Ladder Clamp (1/2" ID Hoses) 444-566 444-566
38 Hour Meter PV5LD-617 PV5LD-617
39 Intake Canister 525DD-614 525DD-614
40 Light Panel / Ribbon Cable 525D-615 525D-615
41 Purge Manifold Assembly N/A 525DD-617
42 Motor Mounts 505IZ-609 505IZ-609
43 Oxygen Outlet Port 525DD-606 525DD-606
44 PC Board 525KS-622 525KS-622
45 Power Cord w/Strain Relief VARIOUS VARIOUS
46 Power Cord Strap MC29D-657 MC29D-657
47 Power Cord Strain Relief N/A N/A
48 Power Switch 505DZ-508 505DZ-508
49 Pressure Regulator MC29D-612 MC29D-612
50 Pressure Relief Valve 515ADZ-614 515ADZ-614
51 Rotary Valve 515ADZ-702 515ADZ-702
52 Sieve Bed 525D-619 525D-619
Wire Harness:
53 Communication Harness/Port 525D-608 525D-608
54 Main Harness 515AKS-623 515AKS-623
55 Rotary Valve Harness 525D-621 525D-621
56 IEC Connector N/A N/A
57 Thermostat N/A N/A
525PS Unit - Serial # "F" (220/230/240V Units)
525PS Unit - Serial # "J" (220/230/240V Units)
