2.5oz [72g]
18oz [515g]
VALVE PARTS
100psi [7 bar]
MATERIALS OF CONSTRUCTION
GAUGE ONLY
P1 = Max Static Air Input Pressure
WITH GUN
Chrome Plated Brass & Anodised Aluminium
FUNCTIONAL DESCRIPTION
AIR INLET PRESSURES
HOUSING
Toughened Glass
3.2 x 1.9 x 1.65 [81 x 49 x 42]
DIMENSIONS
L x H x W Inches [mm]
SPECIFICATIONS
WEIGHT
ENVIRONMENTAL
Die Cast Aluminium, Chrome Plated
104°F Nominal [40°C]
The DV1 Digital Pressure Gauge is an intrinsically safe device, approved to regulations UL61010-1
Ed.3, UL60079-0 Ed.6, UL60079-11 Ed.6.
The gauge is either supplied as a retrofit kit to existing DV1 sprayguns, or factory installed.
The gauge is powered by a long life battery and has a life expectancy of 2 years under normal shift
working conditions (following a max. 2 year shelf life).
Max Ambient Operating Temperature
WINDOW
SB-E-9-224 R1.0
