HW008 Folding Scooter Owner’s Handbook Page 5
1. Position the scooter with rear wheels and anti-tip
wheels on the ground (as shown below):
2. Insert the key in to the ignition of the scooter and
switch the scooter on.
3. The green button (arrowed
below) on the scooter
should now be illuminated.
Press this for 3 seconds
then release the button
and the scooter will
automatically fold out.
Alternatively, press the
green button on the
remote.
(If case of emergency, press the red button on the
rear of the scooter to stop the folding procedure. If
this happens, remove the hazard and keep your
finger on the green button until the scooter is fully
folded out).
4. Switch off the
scooter using
the key and lift
up the backrest
(highlighted in
the diagram
right)
1. The user should vacate the scooter.
2. Fold down the backrest of the seat (highlighted
on the diagram below).
3. The red button (arrowed
below) on the scooter
should now be
illuminated. Press this for
3 seconds then release
the button and the
scooter will automatically
fold up.
Alternatively, press the
red button on the remote.
(If case of emergency, press
the green button on the rear
of the scooter the stop the
folding procedure. If this
happens, remove the hazard
and keep your finger on the
red button until the scooter
is fully folded up).
4. Switch the scooter off using the ignition and
remove the key.
5. Store the scooter in the holdall (if required).
The holdall features holes in the bottom for the
scooter front wheel and anti-tip wheel to go
through. This is to allow the scooter to be pushed
even when in the holdall.
