DeVilbiss Intellipap DV5HH - Quick View Menu Layout; Quick View Display Diagram; SmartCode Data and Definitions

 

The Quick View Menu shows a summary of information which is reported in the SmartCode data. Information in the Quick
View includes: Number of days used more than 4 hours (or can be set to 5 hours by clinician), AHI (Apnea/Hypopnea
Index), High Leak percent (percent of time at leak >95 L/m), and Daily Usage (average hours per day used). Each
parameter can be viewed in any of four time periods, 1 day, 7 days, 30 days and 90 days.
The following chart shows the Quick View information that is available on your CPAP display if viewing this information has
been enabled by your provider. The Quick View menu shows a summary of your SmartCode data for 1, 7, 30, and 90 day
periods. Each of the time periods contains info for “Number of Days > x hrs”, Apnea Hypopnea Index (AHI), High Leak %
(>95 L/m) and Average Daily Hours of while breathing use.
DiagramofCPAPdisplays
Days≥4H 1d
1/1(100%)
AHI 1d
31.5+
HighLeak 1d
31+%
DailyUsage 1d
9.3+hours
ExitMenu
Press
Days≥4H 7d
7/7(100%)
AHI 7d
31.5+
HighLeak 7d
31+%
DailyUsage 7d
9.3+hours
Days≥4H 30d
30/30(100%)
AHI 30d
31.5+
HighLeak 30d
31+%
DailyUsage 30d
9.3+hours
Days≥4H 90d
90/90(100%)
AHI 90d
31.5+
HighLeak 90d
31+%
DailyUsage 90d
9.3+hours
UP () DOWN () buttons
RIGHT () LEFT () buttons

Your Healthcare provider may contact you to retrieve SmartCode data and Adherence Score information. To display the
SmartCode data, press the LEFT arrow key once. Use the UP arrow or DOWN arrow keys to change the SmartCode
reporting period. Press the LEFT arrow key again to display the Adherence Score.

Not all of the features in the table below are available in all models; some are optional and some depend on what your
physician and/or home care provider has selected. The table shows the items you may see, and describes the feature
associated with each item. Also, some features are only available in certain modes or with the DeVilbiss SmartLink
Therapy Management Module – these are noted in the ‘Mode’ column below. If you do not see some of these options, your
model or conguration does not support them.
Please note that the values displayed are examples only.
DisplayExample Description Mode
OFF
Blower OFF, the CPAP unit is plugged in to AC or DC power with the
blower OFF.
All
QuickViewMenu
Press
Pressing the down key enters the Quick View menu. NOTE:The “Quick
View” menu is only shown if enabled from the clinical menu.
All
P:5.0 Auto
Heat:Off
This is the default screen when the device is turned on. The actual mask
pressure and heater setting are shown. The displayed pressure may vary
slightly while breathing. If the heater system is not connected, the heat
setting will be blank.
All
UpperLimit
15.0cmH2O
This is a prescription setting which limits the maximum pressure at which
the device will operate if in AutoAdjust mode. Your home care provider
programs this setting for you during device setup.
AutoAdjust
Mode
LowerLimit
5.0cmH2O
This is a prescription setting which sets the minimum pressure at which the
device will operate in AutoAdjust mode. Your home care provider programs
this setting for you during device setup.
AutoAdjust
Mode
