If quick connect couplings are required, use only high flow quick connects. Other types will not flow
enough air for correct gun operation.
To clean air cap and fluid tip, brush exterior with a stiff bristle brush. If necesarry to clean cap holes,
use a broom straw or toothpick if possible. If a wire or hard instrument is used, extreme care must be
taken to prevent scratching or burring of the holes which will cause a distorted spray pattern.
To clean fluid passages, remove excess material, then flush with gun wash solution. Wipe the gun
exterior with a dampened cloth. Never completely immerse in any solvent or cleaning solutions as this
is detrimental to the lubricants and life of the spray gun.
SPRAY GUN MAINTENANCE & CLEANING
SPRAY GUN DISASSEMBLY / ASSEMBLY
