DeWalt DCD780 Instruction Manual

English
13
MAINTENANCE
WARNING: To reduce the risk of serious personal injury,
turn tool off and remove the battery pack before making
any adjustments or removing/installing attachments or
accessories. An accidental start-up can cause injury.
Cleaning
WARNING: Blow dirt and dust out of all air vents with clean, dry
air at least once a week. To minimize the risk of eye injury, always
wear ANSI Z87.1 approved eye protection when performing this.
WARNING: Never use solvents or other harsh chemicals for
cleaning the non-metallic parts of the tool. These chemicals may
weaken the plastic materials used in these parts. Use a cloth
dampened only with water and mild soap. Never let any liquid get
inside the tool; never immerse any part of the tool into a liquid.
CHARGER CLEANING INSTRUCTIONS
WARNING: Shock hazard. Disconnect the charger from the AC
outlet before cleaning. Dirt and grease may be removed from the
exterior of the charger using a cloth or soft non-metallic brush. Do
not use water or any cleaning solutions.
Accessories
WARNING: Since accessories, other than those offered by
D
EWALT, have not been tested with this product, use of such
accessories with this tool could be hazardous. To reduce the risk
of injury, only D
EWALT recommended accessories should be used
with this product.
Recommended accessories for use with your tool are available at
extra cost from your local dealer or authorized service center. If you
need assistance in locating any accessory, please contact D
EWALT
Industrial Tool Co., 701 East Joppa Road, Baltimore, MD 21286,
call 1-800-4-D
EWALT (1-800-433-9258) or visit our website: www.
dewalt.com.
MAXIMUM RECOMMENDED CAPACITIES
DCD780 DCD785
WOOD
Auger
7/8" (22 mm) 7/8" (22 mm)
Paddle
1-1/4" (32 mm) 1-1/4" (32 mm)
Twist
1/2" (13 mm) 1/2" (13 mm)
Self-feed
1-3/8" (35 mm) 1-3/8" (35 mm)
Hole saw
2" (50 mm) 2" (50 mm)
METAL
Twist
1/2" (13 mm) 1/2" (13 mm)
Hole saw
1-3/8" (35 mm) 1-3/8" (35 mm)
MASONRY
Carbide
– 1/4" (6.5 mm)
Repairs
The charger and battery pack are not serviceable.
To assure product SAFETY and RELIABILITY, repairs, maintenance
and adjustment (including brush inspection and replacement)
should be performed by a D
EWALT factory service center, a
D
EWALT authorized service center or other qualified service
personnel. Always use identical replacement parts.
Register Online
Thank you for your purchase. Register your product now for:
• WARRANTY SERVICE: Registering your product will help you
obtain more efficient warranty service in case there is a problem
with your product.

DeWalt DCD780 Specifications

General

Chuck capacity (max)	13 mm
Chuck capacity (min)	1.5 mm
Idle speed (1st gear)	600 RPM
Idle speed (2nd gear)	2000 RPM
Drilling diameter in wood (max)	38 mm
Maximum torque (hard applications)	60 N⋅m
Maximum torque (soft applications)	23 N⋅m
Product color	Black, Yellow
Product design	Pistol grip drill
Power source	Battery
Battery voltage	18 V
Battery capacity	4 Ah

Weight and Dimensions

Depth	80 mm
Width	190 mm
Height	236 mm
Weight	1840 g
