DeWalt DCH363 Original Instructions

34
ENGLISH
CORDLESS ROTARY HAMMERDRILL
DC228, DC229, DC232, DC233, DC234, DC235
Congratulations!
You have chosen a DEWALT tool. Years of experience, thorough product development and innovation
make D
EWALT one of the most reliable partners for professional power tool users.
Technical Data
DC228 DC229 DC232 DC233 DC234 DC235
Voltage V 28 28 36 36 36 36
Type 2 2 3 3 3 3
No-load speed min
-1
0 -1,150 0 -1,150 0 - 1,150 0 - 1,150 0 - 1,150 0 - 1,150
Load speed min
-1
0 - 850 0 - 850 0 - 850 0 - 850 0 - 850 0 - 850
Impact energy (EPTA 05/2009)
J 2.1 2.1 2.1 2.1 2.1 2.1
Maximum drilling range in
steel/wood/concrete mm 13/30/24 13/30/24 13/30/24 13/30/24 13/30/24 13/30/24
Tool holder SDS Plus
®
SDS Plus
®
SDS Plus
®
SDS Plus
®
SDS Plus
®
SDS Plus
®
Collar diameter mm 54 54 54 54 54 54
Weight (without
battery pack) kg 3.6 3.6 3.8 2.7 2.9 4.7
L
PA
(sound pressure) dB(A) 82 82 82 82 82 82
K
PA
( sound pressure
uncertainty) dB(A) 2.0 2.0 1.9 1.9 1.9 1.9
L
WA
(sound power) dB(A) 96 95 96 96 96 96
K
WA
( sound power
uncertainty) dB(A) 2.3 2.4 1.9 1.9 1.9 1.9
Vibration total values (triax vector sum) determined according to EN 60745:
Vibration emission value a
h
Drilling into metal
a
h,D
= m/s² < 2.5 < 2.5 < 2.5 < 2.5 < 2.5 < 2.5
Uncertainty K = m/s² 1.5 1.5 1.5 1.5 1.5 1.5
Vibration emission value a
h
Drilling into concrete
a
h,HD
= m/s² 8 8 8.5 8.5 8.5 8.5
Uncertainty K = m/s² 1.5 1.5 1.7 1.7 1.7 1.7
Vibration emission value a
h
Chiselling
a
h,Cheq
= m/s² 5.5 5.5 – 4.5 4.5 4.5
Uncertainty K = m/s² 1.5 1.5 – 1.5 1.6 1.6
Vibration emission value a
h
Screwdriving without impact
a
h
= m/s² < 2.5 < 2.5 < 2.5 < 2.5 < 2.5 < 2.5
Uncertainty K = m/s² 1.5 1.5 1.5 1.5 1.5 1.5
