43
ENGLISH
• Connect the brown lead to the live terminal in the
plug.
• Connect the blue lead to the neutral terminal.
WARNING: No connection is to be made
to the earth terminal.
Follow the fitting instructions supplied with good
quality plugs. Recommended fuse: 3 A.
Using an Extension Cable
An extension cord should not be used unless
absolutely necessary. Use an approved extension
cable suitable for the power input of your charger
(see technical data). The minimum conductor size
is 1 mm
2
; the maximum length is 30 m.
When using a cable reel, always unwind the cable
completely.
ASSEMBLY AND ADJUSTMENT
WARNING: Prior to assembly and
adjustment, always remove the battery
pack.
WARNING: Always switch off the tool
before inserting or removing the battery
pack.
WARNING: Use only DEWALT battery
packs and chargers.
Fitting and removing the battery pack (fi g. A)
• To fi t the battery pack (11), line it up with the
receptacle on the tool. Slide the battery pack
into the receptacle and push until the battery
snaps into place.
• To remove the battery pack, push the release
button (12) while at the same time pulling the
battery pack out of the receptacle.
Selecting the Operating Mode (fi g. C)
The tool can be used in the following operating
modes:
Rotary drilling: for screwdriving and for
drilling into steel, wood and plastics
Hammerdrilling: for concrete and
masonry drilling.
Hammering only: for light chipping.
• To select the operating mode, press the safety
lock (4) and rotate the mode selector switch
(3) until it points to the symbol of the required
mode.
• Release the safety lock and check that the
mode selector switch is locked in place.
WARNING: Do not select the operating
mode when the tool is running.
Inserting and Removing SDS Plus
®
Accessories
(fi g. D)
Your rotary hammerdrill uses SDS Plus
®
accessories (refer to the inset in fi g. D for a cross-
section of an SDS Plus
®
bit shank).
• Clean and grease the bit shank.
• Insert the bit shank into the tool holder (5).
• Push the bit down and turn it slightly until it fi ts
into the slots.
• Pull on the bit to check if it is properly locked.
The hammering function requires the bit to be
able to move axially several centimetres when
locked in the tool holder.
• To remove a bit pull back the tool holder locking
sleeve (15) and pull out the bit.
Fitting the side handle (fi g. E)
The side handle (9) can be fi tted to suit both
right-hand and left-hand users.
WARNING: Do not use the tool without
the side handle properly assembled.
• Loosen the side handle.
• For RH-users, slide the side handle clamp over
the collar behind the tool holder, handle at the left.
• For LH-users, slide the side handle clamp over
the collar behind the tool holder, handle at the
right.
• Rotate the side handle to the desired position
and tighten the handle.
Setting the Drilling Depth (fi g. F)
• Insert the required drill bit.
• Slacken the side handle (9).
