DeWalt DCS778

27
ENGLISH
English (original instructions)
Congratulations!
You have chosen a
DeWALT
tool. Years of experience, thorough product
development and innovation make
DeWALT
one of the most reliable
partners for professional power toolusers.
Technical Data
DCS778
Voltage V
DC
54
Type 1
XPS Yes
Blade diameter mm 250
Blade bore mm 30
Max. blade speed min
-1
4100
Mitre (max. positions) left and right 50°
Bevel (max. positions) left 48°
Compound mitre bevel 45°
mitre 45°
Capacities
cross-cut 90° mm 85 x 305
mitre 45° mm 85 x 215
mitre 48° mm 85 x 204
bevel 45° mm 58 x 305
bevel 48° mm 54 x 305
Overall dimensions mm 465 x 615 x 390
Weight (without battery) kg 15.8
Noise values according to EN61029:
L
PA
(sound pressure) dB(A) 91
L
WA
(acoustic power) dB(A) 100
K (acoustic power uncertainty) dB(A) 3
Battery pack DCB546
Battery type Li-Ion
Voltage V
DC
18/54
Capacity Ah 6.0/2.0
Weight kg 1.05
Charger DCB118
Mains voltage V
AC
230
Battery type 18/54 Li-Ion
Approx. charging time of
battery packs
min 22 (1.3 Ah) 22 (1.5 Ah) 30 (2.0 Ah)
45 (3.0 Ah) 60 (4.0 Ah) 75 (5.0 Ah)
60 (6.0 Ah)
Weight kg 0,66
The DCB118 charger accepts 18V Li-Ion XR and XRFLEXVOLT
TM
battery
packs (DCB181, DCB182, DCB183, DCB183B, DCB184, DCB184B, DCB185
andDCB546).
Fuses:
Europe 230V tools 10 Amperes. mains
U.K. & Ireland 230V tools 3 Amperes. in plugs
EC-Declaration of Conformity
Machinery Directive
Cordless Cross-cut Mitre Saw
DCS778
DeWALT
declares that these products described under Technical Data are
in compliance with:
2006/42/EC, EN61029-1:2009 + A11:2010, EN61029-2-9:2012 + A11:2013.
These products also comply with Directive, 2014/30/EU and 2011/65/EU.
For more information, please contact
DeWALT
at the following address or
refer to the back of themanual.
The undersigned is responsible for compilation of the technical file and
makes this declaration on behalf of
DeWALT
.
Markus Rompel
Director Engineering
DeWALT
, Richard-Klinger-Straße 11,
D-65510, Idstein, Germany
20.04.2016
WARNING: To reduce the risk of injury, read the instructionmanual.
Safety Instructions

WARNING: Read all safety warnings and all instructions. Failure
to follow the warnings and instructions may result in electric shock,
fire and/or seriousinjury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE
General Safety Rules
1 . Keep work areaclear.
Cluttered areas and benches inviteinjuries.
2 . Consider work areaenvironment.
Do not expose the tool to rain. Do not use the tool in damp or wet
conditions. Keep the work area well lit (250–300 Lux). Do not use the tool
where there is a risk of causing fire or explosion, e.g., in the presence of
flammable liquids andgases. Work area should be wellventilated.
3 . Guard against electricshock.
Avoid body contact with earthed surfaces (e.g., pipes, radiators, cookers
and refrigerators). When using the tool under extreme conditions (e.g.,
high humidity, when metal swarf is being produced, etc.), electric safety
can be improved by inserting an isolating transformer or a (FI) earth-
leakage circuit-breaker.
4 . Keep other personsaway.
Do not let persons, especially children, not involved in the work, touch the
tool or the battery and keep them away from the workarea.
5 . Store idletools.
When not in use, tools must be stored in a dry place and locked
up securely, out of reach ofchildren.
6 . Do not force thetool.
It will do the job better and safer at the rate to which it wasintended.
7 . Use the righttool.
Do not force small tools to do the job of a heavy duty tool. Do not use tools
CORDLESS CROSSCUT MITRE SAW
DCS778
