VIBRO KIT
TECHNICAL REFERENCE MANUAL
5 Specifications HW v1.3
Parameter
Value
Unit
Power supply Input Voltage
10 … 26
V
Power supply Input Current Limit
6
A
Control Input Voltage range (Analog
mode)
0 … 10
V
Control Input Voltage levels (PWM
mode)
TTL (3,3V or 5V)
Control Input Frequency max (PWM
mode)
5
kHz
Tacho Output Voltage levels
TTL (3,3V)
Default Tacho resolution
18
PPR
Left Encoder
1024
P/R
Right Encoder
360
P/R
6 User interface FW v1.9
After power-up, the Main Menu is shown. Select one of the following modes:
1. MANUAL
2. RAMP
3. ANALOG
4. PWM IN
6.1 Manual mode
● Set output voltage to some low value. Enable motor by holding RUN_SW for 1sec. ON is displayed.
● Disable motor by pressing RUN_SW shortly. OFF is displayed.
● Set desired motor voltage with encoder, range 0,00…6,00V steps 0,10V.
● Motor speed is shown in RPM, should use 18 PPR tacho wheel for correct reading.
● Check Voltage needed for desired RPM. Depends on bearing wear and other factors. Approx:
VIBRO KIT V20-1 22/29
