VIBRO KIT

TECHNICAL REFERENCE MANUAL

3.3.2 Optical sensor below taped disk

Integrated optical sensor on the bottom side of the chassis for measuring signal of the striped tape on

the rotating disc which is afﬁxed on the shaft of the motor.

Please see chapter 3.3.1. Encoders to deﬁne which sensor has Tacho 1 output and which has Tacho 2

output.

Image 2: Vibro-kit unit

VIBRO KIT V20-1 7/29
