VIBRO KIT
TECHNICAL REFER
ENCE MANUAL
3.3.4 Back panel
Image 4: Back panel of driv
e par
t
Po
wer supply connector
Pin
Name
Description
1
V +
Po
wer supply 12V
...36V
2
V -
Ground
VIBRO KIT V20-
1
9/29
8
10
Table of Contents
