3 Technical data
3.1 Introduction
The new VIBRO-KIT is a compact tool for simulating rotating machinery measurements. It is meant for
demonstrations or educational purposes such as in a lab or university. It provides a playground for
almost unlimited experiments.
It's made of solid aluminum. It’s built of a small electric motor with a simple control panel, two bearings,
two optical strip-tape angle sensors, two encoders and two different couplings on each side. One is rigid
and the other is made of spring.
The RPM can be controlled manually by a turn knob, or you can completely define ramps, cycles, etc.
with the built-in display.
Furthermore, an external analog voltage (or even PWM signal) can be used to control the RPM.
Functionalities:
● Manual RPM control (turn knob, display)
● Definable ramps (runup, coast down, hold time and multiple cycles)
● RPM control by external voltage (e.g. step curve)
● External PWM input
● Different angle sensors (2 optical strip tape, 2 Encoders)
3.2 Scope of supply
Screws 10pcs M3x4, 10pcs M3x6, 10 pcs M3x8, 10pcs M3x10
Nuts 20pcs M3x2.3
