Dexter Laundry A Series User Manual

97
8514-300-00
1 REV PR
Soluon Check VFD light code before turning off power.
Turn the power off to the washer. Check the
wiring connecons to the S1, S2, and +24V drive
jumper connecons. If no problem is observed,
turn on power to the washer and test. If
problem reappears, contact your Dexter
representave.
DRIVE STL VFD Internal
Hardware Error
Condion This error occurs when the drive detects an
open circuit in either the S1/+24V or S2/+24
drive jumper connecons.
Delay Occurs following the “DELAY” error (see
corresponding detail)
Acon Stop the machine and clear the cycle. Keep the
door locked unl the machine has stopped
moving and then unlock the door.
Soluon Check VFD light code before turning off power.
Turn the power off to the washer. Check the
wiring connecons to the S1, S2, and +24V drive
jumper connecons. If no problem is observed,
turn on power to the washer and test. If
problem reappears, contact your Dexter
representave.
DRIVE_PHLI VFD Input Phase
Loss
Condion This error occurs when an input phase loss is
detected
Delay Occurs following the “DELAY” error (see
corresponding detail)
Acon Stop the machine and clear the cycle. Keep the
door locked unl the machine has stopped
moving and then unlock the door.
Soluon Check VFD light code before turning off power.
Turn the power off to the washer. Check the
wiring connecons to the drive and motor. If no
problem is observed, turn on power to the
washer and test. If problem reappears, contact
your Dexter representave.
DRIVE_PHLO VFD Output
Phase Error
Condion This error occurs when an issue is detected with
the drive output phases
Delay Occurs following the “DELAY” error (see
corresponding detail)
Acon Stop the machine and clear the cycle. Keep the
door locked unl the machine has stopped
moving and then unlock the door.
Soluon Check VFD light code before turning off power.
Turn the power off to the washer. Check the
wiring connecons to the drive and motor. If no
problem is observed, turn on power to the
washer and test. If problem reappears, contact
your Dexter representave.
MOTOR_OL VFD Motor
Overheang
Condion This error occurs when the VF AC motor drive is
overheang
Delay Occurs following the “DELAY” error (see
corresponding detail)
