Dexter Laundry T-950 - Variable Frequency Drive Adjustments

8514-296-001 REV K page 51
2.11.5 VARIABLE FREQUENCY DRIVE ADJUSTMENTS (208-240V 60 Hz T-950 model
only)
The variable frequency drive allows for varying acceleration during
Final Spin on T-950 models. It is important to utilize a decreased
acceleration rate when the application power is low. This
acceleration rate is determined by a white wire jumper installed on
the drive terminal block from +10V to AVI. Reference the diagram
below for terminal block locations.
Remove the wire jumper when input power is between 208 and
219 volts. Keep the jumper installed when input power is between
220 and 240 volts. Reference the drawings below for the jumper
location.
Control Terminations on Variable Frequency Drive
MI1
MI2
MI3
MI4
MI5
MI6
DCM
(Left)
DCM
(Right)
24V
ACM
AVI
ACI
10V
M01
200G X X
200G
C Series
Washer
Model
Max
Spin
Speed
Input
Voltage
Jumper Terminal Locations on Variable Frequency Drive (VFD)
T-950
240V
208V
No Jumper required
